The fiber laser welding machine for stainless steel is a high-precision tool designed for welding stainless steel materials. It utilizes advanced fiber laser technology to produce clean, efficient welds with minimal heat distortion.
Product Paramenters
|
Laser power |
1000W/1500W/2000W/3000W |
|
Wavelength |
1064±10nm |
|
Working mode |
CW / pulsed |
|
Beam quality |
M2＜1.1；M2,＜1.15；M2,＜1.2 |
|
Laser stable |
±2% |
|
power supply |
AC220V±10% 50/60Hz ; AC380V±10%3P+PE |
|
Power consumption |
≤4KW；≤5KW；≤6KW |
|
WeldingHead |
KEYI Customized HD-X1 ; KEYI Customized HD-X2 |
|
Cooling system |
Customized Industrial Double Temperature and Double Couble Chiller |
|
Fible length |
5-10m，can be customized |
|
Working condition |
15~35℃ |
|
Humidity environment |
＜70%，no condensation |
|
Welding thickness range |
Max.1mm；Max.3mm；Max.5mm； |
|
Application materials |
Carbon steel,stainless steel,galvanized sheet etc. |
|
Welding speed |
0-150mm/s |
Application
Fiber laser welding machine for stainless steel is widely used in the manufacturing of high-precision parts, medical equipment, aerospace industry, and automotive industry due to its high welding speed, accuracy, and quality.
Company Profile
Wuhan Keyi Optic & Electric Technology Co., Ltd. is a new & hi-tech enterprise ,located in international famous manufacturing city--Wuhan,integrated the laser,precision machinery,CNC and modern management,specializing in developing ,manufacturing and selling of industrial laser equipment and customized automation device.
Our Main Products Including Laser Marking Machine, Laser Welding Machine, Laser Cleaning Machine, Laser Cutting Machine and Laser Engraving Machine.
FAQ
Q1: I know nothing about this machine, what type of machine should I choose?
A:We will help you choose the suitable machine and share you the solution; you can share us the following information
1. What material will you weld
2. The welding material thickness
3. Is it joint welding or over-lay welding
4. What is the exact usage for the machine , for product welding or repair or other application
Q2: When I got this machine, but I don’t know how to use it. What should I do?
A:We will send operation video and manual for the machine. Our engineer will do training online. If needed, we can send our engineer to your site for training or you can send the operator to our factory for training.
Q3: If some problems happen to this machine, what should I do?
A:We provide two years machine warranty. During the two-year warranty, in case any problem for the machine, we will provide the parts free of charge (except for artificial damage). After the warranty, we still provide whole lifetime service. So any doubts, just let us know, we will give you solutions.
Q4: What’s package, will it protect the products?
A: We have 3 layers package. For the outside, we adopt wooden cases free of fumigation. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by waterproof plastic film.
Q5: What’s delivery time?
A: As per your requirement , we will suggest the suitable machine
. The exact delivery time as per your machine. Q6: What payment terms can you accept? A: Any payment is possible for us , like TT, LC, Western Union, Paypal, E-Checking, Master Card, Cash etc.
Q6: How is the shipping method?
A: As per your actual address, we can effect shipment by sea, by air, by truck or railway. Also we can send the machine to your office as per your requirement .
