A laser welder is one of the laser processing machines used for welding and cutting metals. The laser beam injects energy into the workpiece, melting it in a very short time, and solidifying it rapidly, reducing distortion after welding. Another feature is that it can be processed faster than traditional welding methods. In addition, fine processing is possible by adjusting the laser's wavelength, energy density and beam spot diameter.
Why Choose Us
Experienced
With over 10 years' experience, has the expertise to deliver high-quality optical and electronic products and services.
Advanced Technology
Our products and services employ cutting-edge technology and state-of-the-art equipment to ensure precision and accuracy.
Efficient Production
Has an efficient production process that reduces wastage, increases output, and ensures timely delivery.
Quality Assurance
We have a strict quality control system that ensures that every product we deliver meets the highest standards of quality.
Laser welding machines are beneficial in a variety of ways. The speed of a laser welding machine is the most significant advantage.
Automation and Computer-Aided Systems make it easier to integrate laser welding. There is a significant improvement in both accuracy and efficiency due to this.
During the welding process, the tools are not damaged in any way.
The laser beams’ focus is extremely precise. Because of this, the weld will last for a long time.
The welding process is significantly faster than that of traditional methods. This allows laser welding to be used in large-scale manufacturing.
Laser welding can be used to manufacture medical industry products that require a high degree of precision.
Compared to other welding techniques, the amount of energy required is significantly less.
After welding, there is no need for additional finishing of the product. Consequently, the welding time and manpower are saved.
The method is non-contact. However, the finished product will be of higher quality, and the machines will last longer because there will be no contacting parts.
Categorization Of Laser Welders
1.Pulsed Laser
The pulsed laser mechanism is ideal for metals that are light in nature and have low thickness. Thus, the pulsed laser makes intermittent exposure on the metallic body. Keeping it safe from burning or melting.
2.The continuous laser
The continuous laser is ideal for welding on parts that have a high thickness and are strong. Moreover, this welding technology is good for refractory surface metals too.
3.Categorization based on the source of laser
Currently, there are three main types of sources of laser for laser welding machines that use one of these laser sources i.e. Fiber laser, CO2 laser, and Nd: YAG laser. Each of these laser sources has their own benefits and are suitable for the different types of welding materials.
4.Fiber Laser Welding Machine
The fiber laser welding machine is ideal for working on metallic parts. Furthermore, it offers great reliability and efficiency. According to estimates, the accuracy of the laser welding machine using fiber laser is close to 25%.
5.CO2 Laser Welders
The CO2 laser welders can provide a great continuous welding beam that creates efficient and durable welds. It can easily penetrate metals and non-metallic bodies.
6.Nd: YAG Laser welders
The Nd: YAG lasers are less energy efficient as compare to the fiber laser welding machines. However, there are certain applications like greater laser control that you cannot achieve with other types of laser sources.
How Does Laser Welding Machines Work?
Laser Welding Technology
The laser welding technology works based on the principle of heat generation by the laser source. Sources of laser in the method also vary and different sources of lasers are suitable for different types of materials and their physical and chemical properties.
Thus, when the beam of high laser energy is focused on a spot of the metal sheet it creates the metal sheet to melt at the spot. The depth of the hole is managed by the various methods of welding and varies accordingly.
This process takes place at the seam of the two metals or materials to be welded together. However, there are multiple methods of laser welding that depend on the type, thickness, and quality of materials to be weld.
Laser Welding Methods
There are multiple methods of laser welding that are largely in use in various industries. Let’s discuss some of these laser welding techniques for you to get a better idea of the process of laser welding.
Conduction Mode Welding
Conduction welding is a method that provides you with a wide weld that is shallow.
Direct heating method
The direct heating method uses thermal conduction from the source of heat. Subsequently, this results in the melting of the base material and ultimately making the weld with the other material.
Energy transmission method
In comparison, the energy transmission method is slightly different and makes use of an intermediate material that conducts the heat from the source to the weld. Usually, it is the absorbent ink that acts as the intermediary material for the transfer of energy.
Conduction/Penetration Mechanism
This mechanism works on medium energy and creates a deeper hole than the conduction method but is shallower than the penetration method.
Penetration or Keyhole Welding Mechanism
The other way to weld by using a laser is by using the keyhole method. This method focuses the beam of the laser onto the material and creates deep penetration of heat. Thus, a hole is created on the spot by this method.
This hole is later filled with metal vapor that forms a bonding material with the other metal. Therefore, the resulting weld makes a great depth to width ratio and creates tight welds that are durable.
Applications of Laser Welders
Automotive Industry
Laser welders find extensive application in the automotive industry for joining metal sheets, body panels, engine parts, and other components. They offer high precision, speed, and repeatability, ensuring consistent and reliable welds.
01
Medical Devices
Laser welding is also extensively used in the medical device industry for welding small, intricate components like catheters, pacemakers, and surgical instruments. Laser welders offer high accuracy and precision, allowing for complex welding geometries.
02
Aerospace Industry
The aerospace industry uses laser welders for welding components made of exotic metals like titanium, aluminum, and nickel alloys. Laser welding offers high strength, accuracy, and speed, making it ideal for joining aerospace components.
03
Electronics Industry
Laser welding is also used in the electronics industry for welding and joining small components, such as microchips, sensors, and circuit boards. Laser welders offer high precision and speed, ensuring consistent and reliable welds.
04
Jewelry Industry
The jewelry industry uses laser welders to join small components, such as prongs, chains, and clasps. Laser welding offers high accuracy and precision, ensuring strong and durable welds without damaging delicate components.
05
Laser Welding Machine Is Generally Composed Of Parts
Laser welding host
The laser welding host mainly produces the laser beam for welding, which is composed of power supply, laser generator, optical path part, control system and other main parts,
Cooling system
Cooling system provides cooling function for laser generator, generally equipped with 1-5 HP water circulating chiller (mainly for welding machine of square and round laser),
Laser welding automatic table or motion system
The system is used to realize the laser welding, the laser beam moves according to the welding track according to the specific requirements, and realize the automatic welding function of the laser. Generally, there are three kinds of motion control forms
workpiece movement, laser head fixation, laser head movement, workpiece fixation, or laser head and workpiece movement. The whole system, through the way of CNC programming, compiles the motion control program to control the workbench movement according to the requirements, And after the simplified programming system, it has the advantages of simple operation, rapid holding without professional technology or education background. In the worktable system of square and circular laser, such as
manipulator motion system, two-dimensional, three-dimensional worktable, four-axis linkage worktable, gantry welding worktable, cantilever worktable, etc., precise welding motion control can be realized
Fixture
Generally, in the process of laser welding, the laser welding fixture is mainly used to fix the welded workpiece, and make it can be repeatedly loaded and unloaded, repeatedly positioned, so as to facilitate the automatic laser welding. Therefore, the fixture is one of the necessary equipment in the laser welding production, especially in the batch production, whether the fixture is designed in place will directly affect the production efficiency and yield, Fangyuan laser has a large number of professional supporting designers, specially designed laser welding clamping solutions for customers, and provided 3D demonstration, so that customers can clearly understand the whole welding scheme
Observation system
Generally, the laser welding machine needs to be equipped with an observation system, which can carry out real-time microscopic observation on the workpiece. It is used to facilitate accurate positioning and check the welding effect in the welding process when preparing the welding program.
The working principle of the laser welding machine is to use a high-energy laser beam to irradiate the surface of the workpiece, causing the workpiece to locally melt, rapidly cool and form a molten pool, and ultimately achieve the purpose of welding. The laser welding machine mainly consists of a laser, an optical system, a workbench, a cooling system, and a control system. The laser is the core part, which generates high-energy laser beams, usually pulsed or continuous lasers. The laser beam is focused and transmitted through the optical system and finally acts on the surface of the workpiece. When performing laser welding, the laser welding machine first heats the surface of the workpiece to partially melt the workpiece. At the same time, the laser beam moves quickly, causing the molten metal to cool and solidify quickly after the laser beam leaves, forming a welded joint. This process can achieve precise trajectory planning and energy control through a computer control system to achieve high-precision welding. Laser welding machines have many advantages. First of all, laser welding can achieve high-precision welding, especially for some micro and precision components, laser welding can achieve better results. Secondly, laser welding can achieve automation and intelligence, improving production efficiency. Additionally, laser welding has the characteristic of rapid heating and cooling, allowing high-speed welding. Finally, laser welding can achieve remote operation, providing the possibility for welding in various complex environments. It should be noted that safety issues need to be paid attention to when using the laser welding machine. Before operating, you need to understand the safe operating procedures of the laser welding machine and avoid dangerous behaviors such as directly observing the laser beam and wearing eye protection. In addition, laser welding machines require regular maintenance to ensure the stability and reliability of the equipment. To achieve quality and efficiency in welding different materials and for various industries, it is necessary to select the appropriate laser welding machine model and parameters according to the actual situation.
What Are Some Tips To Maintain Your Laser Welding Machine?
Read the Manufacturer's Manual
Start by thoroughly reading and understanding the manufacturer's manual for your specific laser welding machine. It provides valuable information on maintenance procedures, recommended maintenance intervals, and safety precautions.
Regular Cleaning
Keep the machine clean and free of dust, debris, and contaminants. Use compressed air or a vacuum with appropriate attachments to remove particles from the machine's interior components. Ensure that the optics and lenses are clean and free of residue.
Inspect Optical Components
Regularly inspect and clean optical components, such as lenses, mirrors, and protective windows. Any dirt or debris on these components can affect the quality of the laser beam and welding results.
Cooling System Maintenance
Check the cooling system regularly to ensure that it is functioning correctly. Clean or replace filters as needed, and monitor the coolant level to prevent overheating. Inspect hoses and connections for leaks.
Check Gas Supply
If your laser welding machine uses assist gases, make sure the gas supply is consistent and that there are no leaks in the gas lines or fittings. Replace gas cylinders as necessary.
Monitor Beam Quality
Use diagnostic tools and software provided by the manufacturer to monitor the laser's beam quality and power output. If you notice any significant deviations, contact a qualified technician for calibration or adjustment.
Inspect and Replace Consumables
Laser welding machines may have consumable parts like nozzles, tips, and electrodes. Inspect these regularly and replace them when they show signs of wear or damage.
Alignment and Calibration
Periodically check and calibrate the machine's alignment to ensure the laser beam is properly focused on the workpiece. Misalignment can lead to welding defects.
Software Updates
Keep the machine's software up to date by installing recommended updates and patches provided by the manufacturer. Updated software often includes performance improvements and bug fixes.
Safety Checks
Regularly inspect safety features and interlocks to ensure they are working correctly. Laser welding machines are equipped with safety mechanisms to protect operators from exposure to laser radiation.
Operator Training
Ensure that machine operators are adequately trained in both machine operation and basic maintenance tasks. Proper training can help prevent accidents and damage to the equipment.
Scheduled Maintenance
Develop a maintenance schedule based on the manufacturer's recommendations. Perform routine maintenance tasks as scheduled to prevent unexpected downtime.
Keep Records
Maintain detailed records of all maintenance activities, including dates, tasks performed, and any issues encountered. This documentation can be valuable for tracking machine performance and identifying trends.
Professional Service
For complex maintenance tasks or repairs, consider hiring a qualified technician or service provider who is experienced in laser welding machine maintenance. By following these tips and staying proactive with your laser welding machine's maintenance, you can maximize its lifespan, efficiency, and reliability, ultimately improving the quality of your welding projects while reducing the risk of unplanned downtime.
